20 Platter Dollies

These dollies come in two Styles:

End Load – Knock-Down (Ships UPS)
End Load – Fully Welded (Motor Freight)

All dollies hold 18″ x 26″ Platters.
(Platters not included.)

Standard Features:

2-7/8″ Spacing between platters.

Both Stainless Steel and Aluminum models are made from heavy wall 1″ square tube.

Units are equipped with 5″ swivel casters.
(2 with brake and 2 without brake.)

Knock-Down Model comes with tool needed for assembly.

For Custom Made Sizes

Part NumberPlatter CapacityMaterial and ConfigurationOverall Dimension Length X Width x HeightApproximate Shpg. Wt.
DL10201820 ELAluminum, FW28″ x 20-1/4″ x 69-1/2″27 lbs
DL10101320 ELSTAINLESS, KD28″ x 20-1/4″ x 69-1/2″48 lbs
WC203005CasterReplacement5″ Without Brake2 LBS
WC203006CasterReplacement5″ With Brake2 LBS
